Function Repository Resource:

LinearAlgebraMod

Source Notebook

Perform matrix operations over a finite field

Contributed by: Daniel Lichtblau

ResourceFunction["LinearAlgebraMod"][op,mat,p]

performs the operation op on matrix mat using prime modulus p.

ResourceFunction["LinearAlgebraMod"][LinearSolve,mat,rhs,p]

solves mat.x ==rhs for x, modulo p.

ResourceFunction["LinearAlgebraMod"][CharacteristicPolynomial,mat,t,p]

computes the characteristic polynomial for square matrix mat using t as the polynomial variable.

ResourceFunction["LinearAlgebraMod"][op]

represents an operator form that can be applied to matrix and modulus arguments.

ResourceFunction["LinearAlgebraMod"][op,p]

represents an operator form, with the operation and modulus both specified, that can be applied to a matrix.

Details and Options

Allowed operations op include Inverse, LinearSolve, NullSpace, RowReduce, Det, CharacteristicPolynomial and MatrixRank.

When LinearSolve is the operation, a vector or second matrix must be given as the right-hand side.

The operation names can be given either as symbols or strings.

The modulus is 0 by default.

ResourceFunction["LinearAlgebraMod"] accepts an Extension option. It must be a univariate polynomial that is irreducible modulo the prime p, or irreducible over the rationals if the modulus is 0.

ResourceFunction["LinearAlgebraMod"] performs linear algebra over a finite field or an algebraic extension of the rationals, with an input matrix comprised of (not necessarily univariate) polynomial functions.

Examples

Basic Examples (11)

Start with a 2×3 polynomial matrix in two variables, one of which will be used as an algebraic extension:

In[1]:=

$mat = {{a^2 x + 1, 2 a x^2 + (a + 6) x + 5, (a^2 + a + 6) x + (3 a + 4)}, {(4 a + 2) x^2 + (a + 2) x + 3, (a^2 + 3 a + 3) x^2 + (a + 4) x + a, x + 1}};$

The polynomial defining the extension:

In[2]:=

Reduce to row echelon form over the finite extension field of integers mod 7 with 7³=343 elements, given as :

In[3]:=

Out[3]=

Compute the inverse of the submatrix comprised of the first two columns:

In[4]:=

Out[4]=

Check that this inverse multiplied by mat gives the 2×2 identity matrix:

In[5]:=

Out[5]=

Use the last column as a right-hand side for a matrix equation:

In[6]:=

Out[6]=

Check the result:

In[7]:=

Out[7]=

Find a basis for the null space of the full matrix:

In[8]:=

Out[8]=

Check that it has only null vectors for mat:

In[9]:=

Out[9]=

Since there are three columns and the null space is generated by one vector, the rank must be 2:

In[10]:=

Out[10]=

Compute the characteristic polynomial for the matrix augmented by a row of ones:

In[11]:=

Out[11]=

Scope (2)

One need not use an extension field:

In[12]:=

$mat = {{a^2 x + 1, 2 a x^2 + (a + 6) x + 5}, {(4 a + 2) x^2 + (a + 2) x + 3, (a^2 + 3 a + 3) x^2 + (a + 4) x + a}};$

In[13]:=

Out[13]=

Verify the inverse:

In[14]:=

Out[14]=

Apart from cancellation of factors, the denominators in the inverse will be constant multiples of the matrix determinant:

In[15]:=

Out[15]=

Use an operator form of LinearAlgebraMod:

In[16]:=

$mat = {{a 2 x + 1, 2 a x^2 + (a + 6) x + 5}, {(4 a + 2) x^2 + (a + 2) x + 3, (a^2 + 3 a + 3) x^2 + (a + 4) x + a}}; rhs = {x^2 + (a + 4)*x + a^2, (a^2 + 3*a + 2)*x^3 - (a^2 + 5)*a + (a^2 + 2*a + 6)}; ext = a^3 + 5 a^2 + 3 a + 4;$

In[17]:=

Out[18]=

Check the solution:

In[19]:=

$PolynomialMod[mat . sol - rhs, {7, a^3 + 5 a^2 + 3 a + 4}]$

Out[19]=

Use an operator form of LinearAlgebraMod with operation and modulus both specified:

In[20]:=

Out[21]=

Use a matrix for the right-hand side:

In[22]:=

$rhs2 = Transpose[{rhs, {x^2 + 3*a*x + 1, (2*a + 5)*x^2 + (5*a + 6)*x + (a + 3)}}]; sol2 = lsm[mat, rhs2, Extension -> ext]$

Out[1]=

Check that first column agrees with the previous solution:

In[23]:=

Out[23]=

Check that the result is correct:

In[24]:=

$PolynomialMod[mat . sol2 - rhs2, {7, a^3 + 5 a^2 + 3 a + 4}]$

Out[24]=

Properties and Relations (2)

Define a matrix of integers:

In[25]:=

Out[26]=

For integer matrices, operations supported by LinearAlgebraMod are equivalent to their built-in counterparts using the Modulus option:

In[27]:=

Out[27]=

Possible Issues (2)

Symbolic linear algebra can suffer from expression swell (the phenomenon wherein outputs and/or intermediate computations get much larger than inputs).

Define a random polynomial matrix generator:

In[28]:=

$randomPolynomialMatrix[{r_, c_}, deg_, height_, vars_List, nterms_] := Table[randomPolynomial[deg, height, vars, nterms], {r}, {c}] randomPolynomial[deg_, height_, vars_, nterms_] := RandomInteger[{0, height - 1}, nterms] . Table[randomMonomial[deg, vars], nterms] randomMonomial[deg_, vars_] := Apply[Times, vars^RandomInteger[{0, deg}, Length[vars]]]$

Create a random 3×3 matrix of polynomials in two variables with up to seven terms having coefficients between 0 and 70, each of which can have a degree up to 4:

In[29]:=

SeedRandom[1234];
dim = 3;
deg = 4;
mod = 71;
randpolymat = randomPolynomialMatrix[{dim, dim}, deg, mod, {x, y}, 7];
rhs = Table[randomPolynomial[deg, mod, {x, y}, 7], dim];

Solve the system:

In[30]:=

Out[30]=

Check the result:

In[31]:=

Out[31]=

Note the difference in size between input and result:

In[32]:=

Out[32]=

Create a 6×6 example:

In[33]:=

SeedRandom[1234];
dim = 6;
deg = 4;
mod = 7;
rpm = randomPolynomialMatrix[{dim, dim}, deg, mod, {x, y}, 7];
rhs = Table[randomPolynomial[deg, mod, {x, y}, 7], dim];

This takes significantly longer:

In[34]:=

Out[34]=

The factor between output and input sizes has also grown:

In[35]:=

Out[35]=

Also note that using the built-in LinearSolve for the non-modular case is also on the slow side, though faster than LinearAlgebraMod:

In[36]:=

Out[36]=

It produces a similarly large result:

In[37]:=

Out[37]=

The determinant can be found somewhat faster:

In[38]:=

Out[38]=

In[39]:=

Out[39]=

Version History

7.0.1 – 05 December 2022
7.0.0 – 01 September 2021

Source Metadata

Citation:
- The method used is an improved version of code from the 1998 Worldwide Mathematica Conference. Another version, containing some revisions, is here.
