Function Repository Resource:

SubexpressionPositions (1.0.0) current version: 1.2.0 »

Source Notebook

Find subexpressions together with their positions

Contributed by: Nikolay Murzin

ResourceFunction["SubexpressionPositions"][expr,opts]

returns an association with position and subexpression of expr that match certain criteria provided in opts.

ResourceFunction["SubexpressionPositions"][expr,levelspec, opts]

finds only subexpressions that appear on the levels specified by levelspec.

ResourceFunction["SubexpressionPositions"][expr,positions, opts]

select from a given list of positions.

Details and Options

ResourceFunction["SubexpressionPositions"] takes the following options:

"OuterMatch"

_→_

outer expressions matching criteria

"InnerMatch"

_→_

inner expressions matching criteria

"OuterMode"

"Any"

"Any" or All

"InnerMode"

"Any"

"Any" or All

"Complement"

False

take a complement of an overall criteria

Heads

True

whether to include expression heads

"OuterMatch" and "InnerMatch" are both assumed to be of the form subExpr→pos (read as "at"), a pair of patterns that would be matched against a subexpression and a relative position under consideration

Relative positions on the right hand side of matching patterns are always of the form {i₁,i₂,…} with non-negative integers i_k. Examples of position patterns include {} for exact position of matched subexpression, _ for any relative position, {___, 0} for heads, and so on.

"OuterMode" and "InnerMode" allow for matching criteria to match either any or all of corresponding subexpressions

Patterns may come in form of a constraint specified using Except.

Examples

Basic Examples (11)

Find all subexpressions:

In[1]:=

Out[1]=

Find subexpressions that match a pattern in the exact same position:

In[2]:=

Out[2]=

In[3]:=

Out[3]=

Find subexpressions with any inner expression matching a specified pattern:

In[4]:=

Out[4]=

Find subexpressions with any outer expression matching a pattern:

In[5]:=

Out[5]=

Find subexpressions that have any inner expression matching a specified pattern and relative position:

In[6]:=

Out[6]=

Find subexpressions that have any outer expression matching a specified pattern and are positioned at given relative position to it:

In[7]:=

$ResourceFunction["SubexpressionPositions"][f[x, g[y, x], g[x, y]], "OuterMatch" -> _g -> {2}]$

Out[7]=

Find subexpressions with any inner subexpression not matching a specified pattern:

In[8]:=

Out[8]=

Find subexpressions with all inner subexpressions not matching a specified pattern:

In[9]:=

Out[9]=

Find subexpressions with all outer expressions matching a specified pattern:

In[10]:=

Out[10]=

Find subexpressions with combined outer and inner matching patterns:

In[11]:=

$ResourceFunction[ "SubexpressionPositions"][{f[x, g[y]], f[a, b], f[h[1], 2], g[x, y], f[a, c[b]]}, "OuterMatch" -> _f -> {2}, "InnerMatch" -> _ -> {1}]$

Out[11]=

Find specific heads:

In[12]:=

$ResourceFunction[ "SubexpressionPositions"][{f[x, g[y]], f[a, b], f[h[1], 2], g[x, y], f[a, c[b]]}, "OuterMatch" -> _g -> {___, 0}]$

Out[12]=

Options (6)

OuterMode (2)

Find subexpressions with all outer expressions matching a given pattern. The {1, 1} position corresponding to x is not present due to having an outer expression matching _g:

In[13]:=

Out[13]=

Find subexpressions matching outer expression with relative position. Positions {2} and {2,2} corresponding to g[y,z] and z are not present because they both have relative position {2}:

In[14]:=

$ResourceFunction["SubexpressionPositions"][f[x, g[y, z]], "OuterMatch" -> Except[_ -> {2}], "OuterMode" -> All]$

Out[14]=

InnerMode (2)

Find subexpressions having all inner expressions matching a given pattern. Positions {2} and {2, 1} of expressions g[y] and y respectively are not present due to both having inner expression matching y:

In[15]:=

Out[15]=

Find subexpressions having all inner expressions matching any but given pattern and relative position. Position {2} corresponding to g[y,z] is not present because it has inner expression matching y at relative position {1}:

In[16]:=

Out[16]=

Complement (1)

Take a complement to the provided criteria:

In[17]:=

Out[17]=

Heads (1)

Ignore heads:

In[18]:=

Out[18]=

Applications (2)

Ignore subexpressions of patterns, conditions and pattern tests, except pattern variables themselves:

In[19]:=

$ResourceFunction["SubexpressionPositions"][f[x_?p, y_ /; q[y]], "OuterMatch" -> Except[((_Pattern | _Condition) -> {__}) | (_PatternTest -> {Except[ 1], ___})], "OuterMode" -> All, Heads -> False]$

Out[19]=

Find subexpressions of list elements together with labeled elements:

In[20]:=

$ResourceFunction[ "SubexpressionPositions"][{Labeled[x, "x"], y, f[x], {g[x, y], Labeled[z, "z"]}}, "OuterMatch" -> (_List -> {_}) | (_Labeled -> {1}), "InnerMatch" -> Except[_Labeled | _List -> {}], "InnerMode" -> All, Heads -> False]$

Out[20]=

Properties and Relations (1)

SubexpressionPositions combines Position and Extract in a convenient way to filter results by relative subexpression positions:

In[21]:=

$ResourceFunction["SubexpressionPositions"][{f[x], y, f[z, a], b, f[]}, "OuterMatch" -> _f -> {1}]$

Out[21]=

In[22]:=

$With[{expr = {f[x], y, f[z, a], b, f[]}}, KeyMap[Append[1]]@ DeleteMissing@ Map[Quiet@Check[Extract[#, {1}], Missing[]] &]@ Select[MatchQ[_f]]@ AssociationMap[First@Extract[expr, {#}] &, Position[expr, _]] ]$

Out[22]=

Version History

1.2.0 – 13 May 2022
1.1.0 – 28 March 2022
1.0.0 – 21 December 2021
