Save a notebook to a file that is formatted to maximize readability when viewing changes in version control systems

Contributed by: Richard Hennigan (Wolfram Research)

ResourceFunction["SaveReadableNotebook"][notebook,"file"]

saves notebook to "file" as a Notebook expression formatted for readability.

Details and Options

In ResourceFunction["SaveReadableNotebook"][notebook,…], notebook can be any of the following:

Notebook[…]

a notebook expression

NotebookObject[…]

a currently open notebook

"path"

a pathname of a saved notebook

ResourceFunction["SaveReadableNotebook"] has the following options:

"ExcludedCellOptions"

{CellChangeTimes,ExpressionUUID}

cell options that should be discarded from the saved notebook

"ExcludedNotebookOptions"

{WindowSize,WindowMargins}

notebook options that should be discarded

Examples

Basic Examples (4)

Get the ResourceFunction:

In[1]:=

Out[1]=

Save a NotebookObject to a human-readable file:

In[2]:=

nb = CreateDocument[{
TextCell["Test notebook", "Title"],
TextCell["This is a test", "Text"],
ExpressionCell[Defer[1 + 1], "Input"],
ExpressionCell[2, "Output"]
}]

Out[2]=

In[3]:=

Out[3]=

In[4]:=

Save a Notebook expression:

In[5]:=

ResourceFunction["SaveReadableNotebook"][
Notebook[{Cell["Hello world", "Text"]}],
FileNameJoin[{$TemporaryDirectory, "readable.nb"}]
]

Out[5]=

In[6]:=

Save a copy of a notebook file that already exists:

In[7]:=

ResourceFunction["SaveReadableNotebook"][
FileNameJoin[{$InstallationDirectory, "Documentation", "English", "System", "ExampleData", "document.nb"}],
FileNameJoin[{$TemporaryDirectory, "readable.nb"}]
]

Out[7]=

In[8]:=

Options (6)

ExcludedCellOptions (3)

By default, some cell options are automatically stripped:

In[9]:=

ResourceFunction["SaveReadableNotebook"][
Notebook[{Cell["Hello world", "Text", ExpressionUUID -> CreateUUID[]]}],
FileNameJoin[{$TemporaryDirectory, "readable.nb"}]
] // FilePrint

Preserve all cell options:

In[10]:=

Ignore specific options:

In[11]:=

ResourceFunction["SaveReadableNotebook"][
Notebook[{Cell["Hello world", "Text", FontColor -> Red, FontSize -> 14]}],
FileNameJoin[{$TemporaryDirectory, "readable.nb"}],
"ExcludedCellOptions" -> {FontColor}
] // FilePrint

ExcludedNotebookOptions (3)

By default, some notebook options are automatically stripped:

In[12]:=

ResourceFunction["SaveReadableNotebook"][
Notebook[{Cell["Hello world", "Text"]}, WindowSize -> {1000, 1000}],
FileNameJoin[{$TemporaryDirectory, "readable.nb"}]
] // FilePrint

Preserve all notebook options:

In[13]:=

Ignore specific options:

In[14]:=

ResourceFunction["SaveReadableNotebook"][
Notebook[{Cell["Hello world", "Text"]}, Background -> Red],
FileNameJoin[{$TemporaryDirectory, "readable.nb"}],
"ExcludedNotebookOptions" -> {Background}
] // FilePrint

Applications (5)

SaveReadableNotebook can be used to create notebook files that are well suited for version control systems that look at changes to files on a line-by-line basis.

Here is a test notebook:

In[15]:=

nb = NotebookPut@Notebook[{
Cell["Test notebook", "Title"],
Cell["This is a test.", "Text"],
Cell[BoxData[RowBox[{"1", "+", "1"}]], "Input"],
Cell[BoxData["2"], "Output"]
}];
NotebookSave[nb, FileNameJoin[{$TemporaryDirectory, "original.nb"}]];

Now make changes to the notebook, then save to a new file:

In[16]:=

It can be difficult to visualize what actually changed:

In[17]:=

$fileDiff[file1_, file2_, max_ : Infinity] := Column@Take[ Flatten@Replace[ SequenceAlignment[Import[file1, "Lines"], Import[file2, "Lines"]], {{a___String}, {b___String}} :> Grid[{ {Item[StringRiffle[{a}, "\n"], Background -> LightRed]}, {Item[StringRiffle[{b}, "\n"], Background -> LightGreen]} }], {1} ], UpTo[max] ];$

In[18]:=

fileDiff[
FileNameJoin[{$TemporaryDirectory, "original.nb"}],
FileNameJoin[{$TemporaryDirectory, "changed.nb"}],
25
]

Out[19]=

Create a formatted version of each notebook and view changes for those files instead:

In[20]:=

$ResourceFunction["SaveReadableNotebook"][ FileNameJoin[{$TemporaryDirectory, "original.nb"}], FileNameJoin[{$TemporaryDirectory, "original_readable.nb"}] ]; ResourceFunction["SaveReadableNotebook"][ FileNameJoin[{$TemporaryDirectory, "changed.nb"}], FileNameJoin[{$TemporaryDirectory, "changed_readable.nb"}] ]; fileDiff[ FileNameJoin[{$TemporaryDirectory, "original_readable.nb"}], FileNameJoin[{$TemporaryDirectory, "changed_readable.nb"}] ]$

Out[21]=

The formatted notebook files still open normally:

In[22]:=

$NotebookOpen[ FileNameJoin[{$TemporaryDirectory, "changed_readable.nb"}]]$

Out[22]=

Requirements

Wolfram Language 11.3 (March 2018) or above

Version History

1.1.1 – 17 June 2022
1.1.0 – 06 May 2022
1.0.0 – 03 December 2018
